Vision

Mounting set 2.5D, camera-laser distance: 400mm

Linelaser for 2.5D- red (660nm)- focus adjustable- Outputpower 40mW- Beam angle 75°

Machine vision Smart Sensor - 800 MHz quad core (ARM Cortex-A9) - 1 GB RAM - 2 GB onboard flash drive - Standard size - FPGA image preprocessing - 2x POWERLINK - Sensor 1.3 MP 165 fps - Line scan support - Lens 8 mm, F4 with adjustable focus - Filter: 385-700 nm (visible), 635-685 nm (red band-pass filter: 2.5D) - Base plate without LED - No LED optics - Polished glass on both sides and high AR coating

PLK Hybridkabel M12 Y-coded, 10.0m ger.

Machine vision Smart Camera - 800 MHz quad core (ARM Cortex-A9) - 2 GB RAM - 2 GB onboard flash drive - Standard size - FPGA image preprocessing - 2x POWERLINK - Sensor 1.3 MP 90 fps - Lens 8 mm, F4 with adjustable focus - LED 16x red/green/blue/lime - Standard LED optics - Polished glass on both sides and high AR coating

POWERLINK hybrid cable - 1.0 m - Connector: Straight

SMART CAMERA CORTEX A9.i.MX6 QUAD CORE, CON INFERENCE ACCELERATOR, SIN LUCES, SIN LED LENS. 1.3 MP-90FPS, LENS S-MOUNT-8MM. F4 1/1.8", GLASS WITH ANTI-REFLECTIVE COATING.

Smart Light, light bar - 2x POWERLINK - IP65 protection - LED red - Standard LED optics (beam angle: 37°) - Transparent

Smart Light, backlight - 150 x 150 mm - IP5x protection - LED red - 2x POWERLINK - Diffuser

Machine vision Smart Camera - 800 MHz quad core (ARM Cortex-A9) - With inference accelerator - 2 GB RAM - 2 GB onboard flash drive - Standard size - FPGA image preprocessing - 2x POWERLINK - Sensor 5.3 MP 43 fps - Line scan support - Lens 12 mm, F4 with adjustable focus - LED 16x red/green/blue/lime - Standard LED optics - Polished glass on both sides and high AR coating

- Vision Smart Sensor
- 800 MHz dual Core (ARM Cortex A9)
- 1 GByte RAM
- 2 GByte Flash-Drive onboard
- Standard size
- FPGA image preprocessing
- 2 x POWERLINK
- Sensor 1,3 MP 90 fps
- Lens 4,6MM, F3,5 with adjustable focus
- LED 16 x red / green / blue / lime
- standard angle LED Optic
- Glass both sides polished and AR coated

- POWERLINK Hybrid cable
- 15,0m
- Connector: straight

Machine vision Smart Camera - 800 MHz quad core (ARM Cortex-A9) - 2 GB RAM - 2 GB onboard flash drive - Standard size - FPGA image preprocessing - 2x POWERLINK - Sensor 1.3 MP 165 fps - Line scan support - Lens 6 mm, F3.5 with adjustable focus - LED 16x red/blue/IR/white - Standard beam LED optics - Polished glass on both sides and high AR coating

- Vision Smart Camera- 800 MHz Quad Core (ARM Cortex A9)- 2 GByte RAM- 2 GByte Flash-Drive onboard- Standard size- FPGA image preprocessing- 2 x POWERLINK- Sensor 3,5 MP 43 fps- Lens 8MM, F4 with adjustable focus- LED 16 x UV- standard angle LED OpticGlass polished and AR coated with diffuser

- Vision Smart Camera- 800 MHz Quad Core (ARM Cortex A9)- 2 GByte RAM- 2 GByte Flash-Drive onboard- Standard size- FPGA image preprocessing- 2 x POWERLINK- Sensor 1,3 MP 165 fps - Linescan capability- Lens 8MM, F4 with adjustable focus- LED 16 x red / blue / IR / white- standard angle LED Optic- Glass polished and AR coated with Polfilter
